The Anatomy of an RF Communication System
When we think about radio communication, the antenna is often the first thing that comes to mind. An antenna is part of a much larger, complex system full of technical components. Behind reliable radio communication are a range of these components working together - from radio equipment to cables, filters, and other RF components that connect everything.
An RF communication system starts with a
radio transmitter/transceiver. A transmitter will convert information (speech or data) into an RF signal. That signal then travels through the system towards the transmitting antenna.
The
coaxial cable will then carry this RF signal between the radio equipment and other components in the system, including the antenna. These cables will come in different constructions, and choosing the right one is down to factors like insertion loss, power handling, connector compatibility, bend radius and the surrounding environment.
Between the radio and antenna, there are components like
filters, duplexers and combiners. A filter is designed to pass wanted frequencies while reducing unwanted signals. A duplexer allows transmitting and receiving signals to share a common antenna, whilst still providing the required isolation. A combiner allows multiple RF signals to be combined into a shared signal path, often so that several radio channels can use a common antenna system.
There are other components that are particularly useful in complex installations and DAS', such as
splitters, tappers and multicouplers. An RF splitter divides an incoming signal between multiple output paths. A tapper takes portions of a signal, while allowing the remaining signal to continue. A multicoupler is used to distribute signals to multiple receivers, or to combine receiver outputs.
The RF signals eventually make their way to
the antenna, which converts the signal into electromagnetic waves that travel through the surrounding environment. An antenna is either omnidirectional (provides coverage across a broad range of horizontal directions), or directional (concentrating their sensitivity or transmitted energy towards a particular direction). Selecting an antenna also depends on several other factors, such as operating frequency, gain, radiation pattern, polarisation, mounting position and the required coverage. Even the surrounding buildings, terrain and other obstacles can impact selection, with certain antennas being specifically engineered for marine and hazardous environments, as well as mobile and portable setups.
